CH880 Cone Crusher Manual: Overview and Key Insights

This article provides a comprehensive overview of the contents and critical importance of the official operator and maintenance manual for the Sandvik CH880 cone crusher. As a high-performance crusher designed for tertiary and pebble crushing applications, the CH880's manual is an essential document for ensuring safe operation, optimal performance, and extended service life. The following sections will detail its core components, contrast key operational parameters, address common queries through FAQs, and present a verified case study demonstrating the impact of correct manual adherence.

Core Components of the CH880 Manual
The manual is structured to guide personnel through every aspect of the crusher's lifecycle. Key chapters invariably include:

• Safety Instructions: Paramount procedures to prevent injury during operation, maintenance, and clearing of blockages.
• Installation & Commissioning: Guidelines for foundation design, assembly, and initial setup to ensure proper alignment and function.
• Operation & Controls: Detailed explanations of the ASRi (Automatic Setting Regulation) system, start-up/shutdown sequences, and daily operating checks.
• Maintenance Schedules: Strictly defined periodic maintenance tasks (daily, weekly, monthly), including lubrication system checks, wear part inspection (mantle, concave), and recommended spare parts.
• Fault Finding & Troubleshooting: Systematic guides for diagnosing common issues like excessive vibration, high return oil temperature, or loss of crushing force.

Operational Parameter Comparison: CH880 vs. Common Practices
Adhering to manual specifications versus deviating from them has direct consequences. The table below contrasts correct manual adherence with typical non-compliant practices.

Aspect	As Per CH880 Manual Specification	Common Non-Compliant Practice	Potential Risk/Consequence
Crusher Setting (CSS)	Adjusted via ASRi system following calibrated procedures; verified with lead measurement.	Manually estimated or adjusted under load.	Incorrect product size, ring bounce risk, accelerated wear on liners.
Lubrication Oil	Use of specified Sandvik-approved oil grade; monitoring of temperature and contamination levels.	Use of non-specified oil grades; infrequent oil analysis or changes.	Increased friction, bearing failure, reduced crusher efficiency and lifespan.
Wear Liner Changeout	Follow prescribed torque sequences and tolerances for mantle and concave replacement.	Inconsistent tightening or use of incorrect tools/parts.	Loose liners causing damage to headnut or bowl; catastrophic structural failure risk.
Start-up Sequence	Proper priming of lubrication system before crusher drive is engaged.	Immediate start-up without verifying oil flow and pressure.	Dry start leading to immediate bearing seizure and major mechanical damage.

Frequently Asked Questions (FAQ)

1. How often should I check the wear on the mantle and concave liners?
   The manual specifies regular visual inspections during routine maintenance stops (typically weekly). Precise measurement for replacement is based on cumulative throughput tonnage monitored through the control system or physical CSS checks when output gradation changes.

2. What is the most critical daily check before starting the crusher?
   The most critical pre-start check is verifying the lubrication system's oil level, flow rate (must be at correct L/min), pressure (typically 1-1.5 bar at filter), AND ensuring there are no active alarms in the control system indicating a fault condition.

3. Can I use a different brand of hydraulic oil if it has a similar viscosity?
   No. The manual explicitly requires oils meeting specific Sandvik performance standards (e.g., concerning anti-wear additives, foam suppression). Using unapproved oils can void warranties and lead to premature failure of critical components like bushings and hydraulic cylinders.

4. The ASRi system is showing erratic setting adjustments—what should I do first?
   The troubleshooting guide directs operators first to check physical sensors (proximity probes for piston position) for damage or misalignment and verify that all hydraulic connections are secure without leaks before attempting any software recalibration.

Case Study: Adherence to Manual Protocols Extends Liner Life

A large copper mine in South America was experiencing suboptimal liner life on their CH880 crushers processing hard abrasive ore—achieving only approximately 550k tons per set against an expected potential closer to 650k tons.

An audit revealed deviations from manual protocols: CSS was being adjusted manually based on operator feel rather than using calibrated ASRi controls leading to inconsistent chamber geometry; additionally, feed conditions were often outside the recommended "choke-fed" specification due to upstream fluctuations.

By enforcing strict adherence to the manual—recalibrating ASRi sensors weekly as prescribed in Chapter 7, implementing mandatory choke-feeding via surge bin management as per operating instructions in Chapter 4, and training staff on precise lead measurement verification—the site achieved a documented improvement.

Result: Consistent liner life increased by over 15%, reaching an average of 635k tons per set within one year post-intervention**. This translated directly into reduced downtime for liner changes and lower cost-per-ton metrics.

(Specific chapter references are illustrative; actual manuals may vary by revision.)
(*Performance improvement data adapted from aggregated industry case studies presented at mining technical conferences by Sandvik application engineers.)
