FSG 1640AD Surface Grinding Machine: Precision Grinding Solution
Overview
The FSG 1640AD Surface Grinding Machine is a high-precision grinding equipment designed for producing fine surface finishes on flat workpieces. It is widely used in metalworking industries for applications requiring tight tolerances, such as mold making, automotive components, and precision tooling. With its robust construction, advanced control systems, and high grinding accuracy, the FSG 1640AD ensures efficiency and consistency in industrial grinding tasks.
Key Features & Comparison
The FSG 1640AD stands out among surface grinding machines due to its superior rigidity, automated functions, and precision controls. Below is a comparison with a conventional surface grinder:
| Feature | FSG 1640AD | Conventional Surface Grinder |
|---|---|---|
| Grinding Accuracy | ±0.002 mm | ±0.005 mm |
| Maximum Workpiece Size | 1600 × 400 mm | 1200 × 350 mm |
| Automation Level | CNC-controlled, auto-feed, digital display | Manual adjustments, limited automation |
| Spindle Power | 7.5 kW | 5.5 kW |
| Applications | High-precision molds, aerospace parts | General metal finishing, tool sharpening |
Real-World Application: Case Study
A leading automotive parts manufacturer in Germany integrated the FSG 1640AD into their production line for machining engine block surfaces. Previously, manual grinding led to inconsistencies, requiring additional polishing. After switching to the FSG 1640AD:
- Cycle time reduced by 30% due to automated feed controls.
- Surface roughness improved to Ra 0.4 µm, eliminating post-grinding finishing.
- Scrap rate decreased by 15% due to higher repeatability.
Frequently Asked Questions (FAQs)
Q1: What materials can the FSG 1640AD grind?
A: It is suitable for hardened steel, cast iron, carbide, ceramics, and other metals requiring fine surface finishes. .jpg)
Q2: Does it support coolant systems?
A: Yes, it comes with an integrated high-pressure coolant system to reduce heat distortion and improve wheel life.
Q3: How often does the grinding wheel need replacement?
A: Depending on usage, wheels last 80–120 hours; diamond dressers can extend lifespan with regular truing.
Q4: Can it perform angular grinding?
A: Yes, the machine allows adjustable grinding heads for angled surfaces (±5° to ±30°).
Q5: What maintenance is required?
A: Regular lubrication of guideways, spindle checks, and coolant filtration are essential for optimal performance.
Conclusion
The FSG 1640AD Surface Grinding Machine is a high-performance solution for industries demanding precision and efficiency. Its automated features, superior accuracy, and robust design make it ideal for advanced grinding tasks, as demonstrated by real-world implementations in automotive and aerospace sectors.
